List of ASTM Material Specifications
ASME pressure & temperature ratings


ASTM Material Specifications
Mat
Group		 Nom
Desig		 Press
Temp
Rating
Table		 Forg
ings		 Cast
ings		 Plates

1.1

 C-Mn-Si 2-1.1 A350 Gr. LF2   A516 Gr. 70
C-Mn-Si 2-1.1     A537 Cl. 1
C-Mn-Si-V 2-1.1 A350 Gr. LF6 CI. 1
3.1/2 Ni 2-1.1 A350 Gr. LF3

1.2

 C-Mn-Si 2-1.2   A216 Gr. WCC
C-Mn-Si 2-1.2   A352 Gr. LCC
C-Mn-Si-V 2-1.2 A350 Gr. LF6 Cl. 2
2.1/2Ni 2-1.2   A352 Gr. LC2 A203 Gr. B
3.1/2Ni 2-1.2   A352 Gr. LC3 A203 Gr. E

1.3

 C-Si 2-1.3   A352 Gr. LCB A515 Gr. 65
C-Mn-Si 2-1.3     A516 Gr. 65
2.1/2Ni 2-1.3     A203 Gr. A
3.1/2Ni 2-1.3     A203 Gr. D
C-1/2Mo 2-1.3   A217 Gr. WC1
C-1/2Mo 2-1.3   A352 Gr. LC1

1.4

 C-Si 2-1.4     A515 Gr. 60
C-Mn-Si 2-1.4 A350 Gr. LF1 Cl. 1   A516 Gr. 60

1.5

 C-1/2Mo 2-1.5 A182 Gr. F1   A204 Gr. A
C-1/2Mo 2-1.5     A204 Gr. B

1.7

 1/2Cr-1/2Mo 2-1.7 A182 Gr. F2
Ni-1/2Cr-1/2Mo 2-1.7   A217 Gr. WC4
3/4Ni-3/4Cr-1Mo 2-1.7   A217 Gr. WC5

1.9

 1.1/4Cr-1/2Mo 2-1.9   A217 Gr. WC6
1.1/4Cr-1/2Mo-Si 2-1.9 A182 Gr. F11 CL.2   A387 Gr. 11 Cl. 2

1.10

 2.1/4;Cr-1Mo 2-1.10 A182 Gr. F22 Cl. 3 A 217 Gr. WC9 A387 Gr. 22 Cl. 2

1.11

 C-1/2Mo 2-1.11     A204 Gr. C

1.13

 5Cr-1/2Mo 2-1.13 A182 Gr. F5a A217 Gr. C5

1.14

 9Cr-1M0 2-1.14 A182 Gr. F9 A217 Gr. C12

1.15

 9Cr-1M0-V 2-1.15 A182 Gr. F91 A217 Gr. C12A A387 Gr. 91 Cl. 2

1.17

 1Cr-1/2Mo 2-1.17 A182 Gr. F12 Cl. 2
5Cr-1/2Mo 2-1.17 A182 Gr. F5

1.18

 9Cr-2W-V 2-1.18 A182 Gr. F92

2.1

 18Cr-8Ni 2-2.1 A182 Gr. F304 A351 Gr. CF3 A240 Gr. 304
18Cr-8Ni 2-2.1 A182 Gr. F304H A351 Gr. CF8 A240 Gr. 304H

2.2

 16Cr-12Ni-2Mo 2-2.2 A182 Gr. F316 A351 Gr. CF3M A240 Gr. 316
16Cr-12Ni-2Mo 2-2.2 A182 Gr. F316H A351 Gr. CF8M A240 Gr. 316H
18Cr-13Ni-3Mo 2-2.2 A182 Gr. F317   A240 Gr. 317
19Cr-10Ni-3Mo 2-2.2   A351 Gr. CG8M

2.3

 18Cr-8Ni 2-2.3 A182 Gr. F304L   A240 Gr. 304L
16Cr-12Ni-2Mo 2-2.3 A182 Gr. F316L   A240 Gr. 316L
18Cr-13Ni-3Mo 2-2.3 A182 Gr. F317L

2.4

 18Cr-10Ni-Ti 2-2.4 A182 Gr. F321   A240 Gr. 321
18Cr-10Ni-Ti 2-2.4 A182 Gr. F321H   A240 Gr. 321H

2.5

 18Cr-10Ni-Cb 2-2.5 A182 Gr. F347   A240 Gr. 347
18Cr-10Ni-Cb 2-2.5 A182 Gr. F347H   A240 Gr. 347H
18Cr-10Ni-Cb 2-2.5 A182 Gr. F348   A240 Gr. 348
18Cr-10Ni-Cb 2-2.5 A182 Gr. F348H   A240 Gr. 348H

2.6

 23Cr-12Ni 2-2.6     A240 Gr. 309H

2.7

 25Cr-20Ni 2-2.7 A182 Gr. F310   A240 Gr. 310H

2.8

 20Cr-18Ni-6Mo 2-2.8 A182 Gr. F44 A 351 Gr. CK3 MCuN A240 Gr. S 31254
22Cr-5Ni-3Mo-N 2-2.8 A182 Gr. F51   A240 Gr. S 31803
25Cr-7Ni-4Mo-N 2-2.8 A182 Gr. F53   A240 Gr. S 32750
24Cr-10Ni-4Mo-V 2-2.8   A351 Gr. CE8MN
25Cr-5Ni-2Mo-3Cu 2-2.8   A995 Gr. CD4MCu
25Cr-7Ni-3.5Mo-W-Cb 2-2.8   A995 Gr. CD3 MWCuN
25Cr-7.5Ni-3.5Mo-N-Cu-W 2-2.8 A182 Gr. F55   A240 Gr. S 32760

2.9

 23Cr-12Ni 2-2.9     A240 Gr. 309S
25Cr-12Ni 2-2.9     A240 Gr. 310S

2.1

 25Cr-12Ni 2-2.10   A351 Gr. CH8
25Cr-12Ni 2-2.10   A351 Gr. CH20

2.11

 18Cr-10Ni-Cb 2-2.11   A351 Gr. CF8C

2.12

 25Cr-20Ni 2-2.12   A351 Gr. CK20

3.1

 35Ni-35Fe-20Cr-Cb 2-3.1 B462 Gr. N 08020   B463 Gr. N 08020

3.2

 99.0Ni 2-3.2 B564 Gr. N 02200   B162 Gr. N 02200

3.3

 99.0Ni-Low C 2-3.3     B162 Gr. N 02201

3.4

 67Ni-30Cu 2-3.4 B564 Gr. N 04400   B127 Gr. N 04400

3.5

 72Ni-15Cr-8Fe 2-3.5 B564 Gr. N 06600   B168 Gr. N 06600

3.6

 33Ni-42Fe-21Cr 2-3.6 B564 Gr. N 08800   B409 Gr. N 08800

3.7

 65Ni-28Mo-2Fe 2-3.7 B462 Gr. N 10665   B333 Gr. N 10665
64Ni-29.5Mo-2Cr-2Fe-Mn-W 2-3.7 B462 Gr. N 10675   B333 Gr. N 10675

3.8

 54Ni-16Mo-15Cr 2-3.8 B462 Gr. N 10276   B575 Gr. N 10276
60Ni-22Cr-9Mo-3.5Cb 2-3.8 B564 Gr. N 06625   B443 Gr. N 06625
62Ni-28Mo-5Fe 2-3.8     B333 Gr. N 10001
70Ni-16Mo-7Cr-5Fe 2-3.8     B434 Gr. N 10003
61Ni-16Mo-16Cr 2-3.8     B575 Gr. N 06455
42Ni-21.5Cr-3Mo-2.3Cu 2-3.8 B564 Gr. N 08825   B424 Gr. N 08825
55Ni-21Cr-13.5Mo 2-3.8 B462 Gr. N 06022   B575 Gr. N 06022
55Ni-23Cr-16Mo-1.6Cu 2-3.8 B462 Gr. N 06200   B575 Gr. N 06200

3.9

 47Ni-22Cr-9Mo-I8Fe 2-3.9     B435 Gr. N 06002
21Ni-30Fe-22Cr-18Co-3Mo-3W 2-3.9 B572 Gr. R 30556   B435 Gr. R 30556

3.1

 25Ni-47Fe-21Cr-5Mo 2-3.10     B599 Gr. N 08700

3.11

 44Fe-25Ni-21Cr-Mo 2-3.11 A479 Gr. N 08904   A240 Gr. N 08904

3.12

 26Ni-43Fe-22Cr-5Mo 2-3.12     B620 Gr. N 08320
47Ni-22Cr-20Fe-7Mo 2-3.12     B582 Gr. N 06985
46Fe-24Ni-21Cr-6Mo-Cu-N 2-3.12 B462 Gr. N 08367 A351 Gr. CN3MN B688 Gr. N 08367

3.13

 49Ni-25Cr-18Fe-6Mo 2-3.13     B582 Gr. N 06975
Ni-Fe-Cr-Mo-Cu-Low C 2-3.13 B564 Gr. N 08031   B625 Gr. N 08031

3.14

 47Ni-22Cr-19Fe-6Mo 2-3.14     B582 Gr. N 06007
40Ni-29Cr-15Fe-5Mo 2-3.14 B462 Gr. N 06030   B582 Gr. N 06030
58Ni-33Cr-8Mo 2-3.14 B462 Gr. N 06035   B575 Gr. N 06035

3.15

 42Ni-42Fe-21Cr 2-3.15 B564 Gr. N 08810   B409 Gr. N 08810

3.16

 35Ni-19Cr-1.1/4Si 2-3.16 B511 Gr. N 08330   B536 Gr. N 08330

3.17

 29Ni-20.5Cr-3.5Cu-2.5Mo 2-3.17   A351 Gr. CN7M

3.19

 57Ni-22CR-14W-2Mo-La 2-3.19 B564 Gr. N 06230   B435 Gr. N 06230

General notes..

  • For temperature limitations, see notes in ASME B16.5 Tables II-2-1.1 through II-2-3.17 of Mandatory Appendix II.
  • Plate materials are listed only for use as blind flanges and reducing flanges without hubs (ASME B16.5 see para. 5.1). Additional plate materials listed in ASME B16.34 may also be used with corresponding B16.34, Standard Class ratings.

Note..

  • ASME Boiler and Pressure Vessel Code, Section II materials may also be used, provided the requirements of the ASME specification are identical to or more stringent than the corresponding ASTM specification for the Grade, Class, or Type listed.
